808d-mte40 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
- - 7/7 U
808d-mte60 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
- - 7/7 U
Description: This setting data is used to define the circle center point in the workpiece coordinate
system during JOG of circles.
Only the relevant center point coordinates of the geometry axes in the active plane
are evaluated, not the coordinate of the geometry axis vertical to the plane. This
setting data is written via the user interface.
By default the coordinate of an axis with diameter programming is in the diameter. This
can be changed with MD20360 $MC_TOOL_PARAMETER_DEF_MASK Bit 13 = 1 by indicating a
radius.
42691 JOG_CIRCLE_RADIUS - -
mm Circle radius DOUBLE Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... - - 2/2 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... - - 2/2 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... - - 2/2 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... - - 2/2 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... - - 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... - - 7/7 U
Description: With this setting data, the circle radius in the machine, the maximum circle during
inner machining or
the minimum circle during outer machining are defined when jogging
circles. This setting data is written via the user interface.
42692 JOG_CIRCLE_MODE - -
- JOG of circles mode DWORD Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0xf 2/2 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0xf 2/2 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0xf 2/2 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0xf 2/2 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0xf 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0xf 7/7 U
Description: This setting data sets the following during JOG of circles:
Bit 0 = 0 :
Travel to + creates traversing on a circular path in counterclockwise direction;
travel to - creates traversing in clockwise direction.
Bit 0 = 1 :
Travel to + creates traversing on a circular path in clockwise direction; travel to -
creates traversing in counterclockwise direction.
Bit 1 = 0 :
The tool radius is not taken into account in checking the limitation produced by the
specified circle or by the circle segment limited by the start and end angles.
Bit 1 = 1 :
The tool radius is taken into account in checking the limitation produced by the
specified circle or by the circle segment limited by the start and end angles.
Bit 2 = 0 :
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 327
