-3= The revolutional feedrate is derived from the master spindle of the channel in
which the axis/spindle is active. No revolutional feedrate is active if the master
spindle is at a standstill.
Related to ....
SD43300: $SA_ASSIGN_FEED_PER_REV_SOURCE (revolutional feedrate for position axes/
spindles)
42660 ORI_JOG_MODE - -
- Definition of virtual kinematics for JOG DWORD Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 5 0/0 S
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 5 0/0 S
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 5 0/0 S
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 5 0/0 S
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 5 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 5 7/7 U
Description: This SD can be used to define virtual kinematics, which become active for the manual
travel of orientations.
This setting data is evaluated only by the generic 5/6-axis transformation. This data
has no meaning for OEM transformations.
The following setting options are available:
0: The virtual kinematics are defined by the transformation.
1: Euler angles are traversed during jog, that is the 1st axis turns round the Z
direction, the 2nd axis turns around the X direction and, if present, the 3rd axis
turns aound the new Z direction.
2: RPY angles are traversed during jog with the turning sequence XYZ, that is the
1st
axis turns
around the x direction, the 2nd axis turns around the Y direction and,
if present, the 3rd axis turns around the new Z direction.
3: RPY angles are traversed during jog with the turning sequence ZYX, that is the
1st axis turns
around the Z direction, the 2nd axis turns around the Y direction and,
if present, the 3rd axis turns around the new X direction.
4: The turning sequence of the rotary axes is set by means of MD21120
$MC_ORIAX_TURN_TAB_1.
5: The turning sequence of the rotary axes is set by means of MD21130
$MC_ORIAX_TURN_TAB_2.
42690 JOG_CIRCLE_CENTRE - -
mm Center of the circle DOUBLE Immediately
-
808d-me42 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
- - 2/2 M
808d-me62 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
- - 2/2 M
808d-te42 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
- - 2/2 M
808d-te62 3 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0...
- - 2/2 M
NC setting data
Parameter Manual
326 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
