808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
Description: TRUE:
If a frame with mirror image machining is active, the tool components
($TC_DP3[..., ...] to $TC_DP5[..., ...]) and the components of the base dimensions
($TC_DP21[..., ...] to $TC_DP23[..., ...]) whose associated axes
are mirrored, are also mirrored, i.e. their sign is inverted. The wear values
are not mirrored. If the wear values are to be mirrored too,
SD42910 $SC_MIRROR_TOOL_WEAR must be set.
FALSE:
The sign for tool length components is unaffected by whether a frame with mirror image
machining is active.
42910 MIRROR_TOOL_WEAR - W1
- Sign change of tool wear with mirror image machining BOOLEAN Immediately
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-te42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-te62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
Description: TRUE:
If a frame with mirror image machining is activated, the signs of the wear values of
the components in question are inverted. The wear values of the components that are
not assigned to mirrored axes remain unchanged.
FALSE:
The signs for wear values are unaffected by whether a frame with mirror image machining
is active.
NC setting data
Parameter Manual
330 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
