Siemens SINUMERIK 808D ADVANCED Parameter Manual

42920 WEAR_SIGN_CUTPOS - W1
- Sign of tool wear depending on tool point direction BOOLEAN Immediately
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-te42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-te62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
Description: TRUE:
In the case of tools with a relevant tool point direction (turning and grinding tools),
the sign for wear of the tool length components depends on the tool point direction.
The sign is inverted in the following cases (marked with an X):
Tool point direction Length 1 Length 2
1
2 X
3 X X
4 X
5
6
7 X
8 X
9
The sign for wear value of length 3 is not influenced by this setting data.
The SD42930 $SC_WEAR_SIGN acts in addition to this setting data.
FALSE:
The sign for wear of the tool length components is unaffected by the tool point
direction.
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 331
