42930 WEAR_SIGN - W1
- Sign of wear BOOLEAN Immediately
-
808d-me42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-me62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-te42 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-te62 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 0/0 S
808d-mte40 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
808d-mte60 - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
Description: TRUE:
The sign for wear of the tool length components and the tool radius are inverted, i.e.
if a positive value in entered, the total dimension is decreased.
FALSE:
The sign for wear of the tool length components and the tool radius is not inverted.
42935 WEAR_TRANSFORM - W1, W4
- Transformations for tool components DWORD Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... - - 0/0 S
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... - - 0/0 S
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... - - 0/0 S
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... - - 0/0 S
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... - - 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... - - 7/7 U
Description: This setting data is bit-coded.
It determines which of the three wear components
wear
($TC_DP12 - $TC_DP14),
additive offsets fine ($TC_SCPx3 - $TC_SCPx5),
and additive offsets coarse ($TC_ECPx3 - $TC_ECPx5)
are subject to adapter transformation and transformation by an orientable tool holder,
if
one of
the two G codes TOWMCS or TOWWCS from G code group 56 is active. If initial-
setting G code TOWSTD is active, this setting data will not become active.
Then, the following assignment is valid:
NC setting data
Parameter Manual
