If the sign of the setting data is negative, the coordinate system is rotated around
the axis by 180 degrees, which is defined by the original position of the normal
orientation vector (that is before any rotation on account of n being unequal to 0).
Example:
If the content of the setting data is -18, then:
Orientation vector (0, -1, 0)
Normal orientation vector (1, 0, 0)
Binormal vector (0 , 0, -1)
Handling of tools with an explicitly programmed tool orientation by using cutting edge
data ($TC_DPV..):
This setting data is normally ignored for tools for which the orientation is defined
in this way. This means that the programmed orientation vectors are assigned to the
geometry axes according to the active machining plane (G17 - G19).
If the setting data is also active for such tools, then the 1000s digit must be equal
to 1. However, the 100s digit and the sign are not evaluated. This means that the
setting
data only
defines how the orientation components are assigned to the geometry
axis directions. No additional rotations are executed.
42970 TOFF_LIMIT - F2
mm Upper limit of correction value via $AA_TOFF DOUBLE Immediately
-
808d-me42 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 0/0 S
808d-me62 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 0/0 S
808d-te42 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 0/0 S
808d-te62 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 0/0 S
808d-mte40 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 7/7 U
808d-mte60 3 10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0, 10.0,
10.0, 10.0, 10.0...
0.0 - 7/7 U
Description: Upper limit of the offset value which can be defined by means of synchronized actions
via the $AA_TOFF system variable.
This limit value influences the absolutely effective amount of offset through $AA_TOFF.
Whether the offset value is within the limit range can be checked via the
$AA_TOFF_LIMIT system variable.
42972 TOFF_LIMIT_MINUS - F2
mm Lower limit of the offset value $AA_TOFF DOUBLE Immediately
-
808d-me42 3 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- 0.0 0/0 S
808d-me62 3 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0,...
- 0.0 0/0 S
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 337
