Optionally, the first character of the string can be written as sign (+ or -). A plus
sign will not have any effect on the angle calculation, but a minus sign will invert
the sign of the calculated angle.
42990 MAX_BLOCKS_IN_IPOBUFFER - K1
- Maximum number of blocks in IPO buffer DWORD Immediately
-
808d-me42 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 1/1 M
808d-me62 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 1/1 M
808d-te42 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 1/1 M
808d-te62 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 1/1 M
808d-mte40 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 7/7 U
808d-mte60 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 7/7 U
42995 CONE_ANGLE - -
- Taper angle DOUBLE Immediately
-
808d-me42 - - -90 90 7/7 U
808d-me62 - - -90 90 7/7 U
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... -359.9 359.9 7/7 U
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... -359.9 359.9 7/7 U
808d-mte40 - - -90 90 7/7 U
808d-mte60 - - -90 90 7/7 U
Description: This setting data writes the taper angle for taper turning. This setting data is
written via the operator interface.
42996 JOG_GEOAX_MODE_MASK - -
- JOG of geometry axis mode DWORD Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 7/7 U
Description: This setting data sets the following during JOG of geometry axes:
Bit 0 = 1 :
A traversing request for the 1st geometry axis is inverted, i.e. a traversing request
to + triggers a traversing motion to - .
Bit 1 = 1 :
A traversing request for the 2nd geometry axis is inverted, i.e. a traversing request
to + triggers a traversing motion to -.
Bit 2 = 1:
A traversing request for the 3rd geometry axis is inverted, i.e. a traversing request
to + triggers a traversing motion to -.
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 341
