43120 DEFAULT_SCALE_FACTOR_AXIS - FBFA
- Axial default scaling factor with G51 active DWORD Immediately
-
- - 1 - - 2/2 M
Description: If no axial scaling factor I, J, or K is programmed in the G51 block, SD43120
$SA_DEFAULT_SCALE_FACTOR_AXIS is active.
The scaling factor is only active if MD22914
$MC_AXES_SCALE_ENABLE is set.
Related to:
MD22914 $MC_AXES_SCALE_ENABLE,
MD22910 $MC_WEIGHTING_FACTOR_FOR_SCALE
43200 SPIND_S - S1
rev/min Speed for spindle start by VDI DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
Description: Spindle speed at spindle start by NC/PLC interface signals DB380x DBX5006.1 (Spindle
start clockwise rotation) and DB380x DBX5006.2 (Spindle start counterclockwise
rotation).
Example: SD43200 $SA_SPIND_S[S1] = 600
Spindle 1 is started at a speed of 600 rpm upon detection of the positive edge of one
of the above-mentioned VDI starting signals.
Speed programming values are entered in the SD by setting bit 4=1 in MD35035
$MA_SPIND_FUNCTION_MASK.
The SD becomes active in JOG mode as a default speed by setting bit 5=1 in MD35035
$MA_SPIND_FUNCTION_MASK (exception: the value is zero).
Related to:
MD35035 $MA_SPIND_FUNCTION_MASK
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43202 SPIND_CONSTCUT_S - S1
m/min Const cut speed for spindle start by VDI DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
Description: Definition of the constant cutting speed for the master spindle.
The setting data is evaluated at spindle start by the NC/PLC interface signals DB380x
DBX5006.1 (Spindle start clockwise rotation) and DB380x DBX5006.2 (Spindle start
counterclockwise rotation)
Cutting speed programming values are entered in the SD by setting bit 8=1 in MD35035
$MA_SPIND_FUNCTION_MASK.
Related to:
MD35035 $MA_SPIND_FUNCTION_MASK
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43206 SPIND_SPEED_TYPE A06 -
- Spindle speed type for spindle start through VDI DWORD Immediately
-
- - 94 93 973 7/7 U
Description: Definition of the spindle speed type for the master spindle.
NC setting data
Parameter Manual
342 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
