Page #349 background imageLoading...
Page #349 background image
43750 OSCILL_NUM_SPARK_CYCLES - P5
- Number of spark-out strokes DWORD Immediately
-
808d-me42 - 0 0.0 - 7/7 U
808d-me62 - 0 0.0 - 7/7 U
808d-te42 - 0 0.0 - 0/0 S
808d-te62 - 0 0.0 - 0/0 S
808d-mte40 - 0 0.0 - 7/7 U
808d-mte60 - 0 0.0 - 7/7 U
Description: Number of sparking-out strokes performed after ending the oscillating movement
Application example(s)
NC language: OSNSC[Axis]=Stroke number
Note:
MD 10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
Related to ....
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43760 OSCILL_END_POS - P5
mm, degrees End position of the reciprocating axis DOUBLE Immediately
-
808d-me42 - 0.0 - - 7/7 U
808d-me62 - 0.0 - - 7/7 U
808d-te42 - 0.0 - - 0/0 S
808d-te62 - 0.0 - - 0/0 S
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: Position the oscillating axis travels to after ending the sparking-out strokes.
Note:
MD 10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
Application example(s)
NC language: OSE[Axis]=Position
Related to ....
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43770 OSCILL_CTRL_MASK - P5
- Oscillation sequence control mask DWORD Immediately
-
808d-me42 - 0 0 0x7FFFFFFF 7/7 U
808d-me62 - 0 0 0x7FFFFFFF 7/7 U
808d-te42 - 0 0 0x7FFFFFFF 0/0 S
808d-te62 - 0 0 0x7FFFFFFF 0/0 S
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 349
