808d-mte40 - 0 0 0x7FFFFFFF 7/7 U
808d-mte60 - 0 0 0x7FFFFFFF 7/7 U
Description: Bit mask:
Bit no. | Meaning in OSCILL_CTRL_MASK
------------------------------------------------------------------------------
0(LSB)-1 | 0: Stop at the next reversal point if the
| oscillating movement is switched off
|
| 1: Stop at reversal point 1 if the
| oscillating movement is switched off
| 2: Stop at reversal point 2 if the
| oscillating movement is switched off
| 3: Do not approach a reversal point when the oscillating movement is
switched off
| if no sparking-out strokes are programmed
------------------------------------------------------------------------------
2 | 1: Approach end position after sparking out
------------------------------------------------------------------------------
3 | 1: If the oscillating movement is canceled by delete distance-to-go,
| then the sparking-out strokes are to be executed afterwards
| and the end position approached if necessary
------------------------------------------------------------------------------
4 | 1: If the oscillating movement is canceled by delete distance-to-go,
| then the corresponding reversal point
| is approached on switch off
------------------------------------------------------------------------------
5 | 1: Changed feedrate does not become active until the next reversal point
------------------------------------------------------------------------------
6 | 1: Path override is active if the feed rate is 0,
| otherwise speed override is active
------------------------------------------------------------------------------
7 | 1: In the case of rotary axes DC (shortest path)
------------------------------------------------------------------------------
8 | 1: Execute sparking-out stroke as single stroke not as double stroke
------------------------------------------------------------------------------
9 | 1: On starting, first approach the starting position, see
| SD43790 $SA_OSCILL_START_POS
------------------------------------------------------------------------------
Application example(s)
NC language: OSCTRL[Axis]=(setting options, reset options)
Related to ....
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43780 OSCILL_IS_ACTIVE - P5
- Activate oscillation movement BOOLEAN Immediately
-
808d-me42 - FALSE 0 - 7/7 U
808d-me62 - FALSE 0 - 7/7 U
NC setting data
Parameter Manual
350 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
