Value
0: 0x1 Comparison commands ">" and "<" are processed as for SW 6.3 and earlier:
Sub-program data of the type REAL are mapped internally in the IEEE 64 bit
format. This mode maps decimal numbers inaccurately if this format's 52-bit wide
mantissa is inadequate to map the number in binary notation. To solve this problem,
all
comparison
commands
( ==, <>, >=, <=, > and < ) are checked for relative equality
of 1E-12.
This procedure is deactivated for greater than (>) and less than ( < )
comparisons by setting bit 0. (Compatibility setting for software releases earlier
than SW 6.4)
1: 0x2 Programming the channel names from machine data MD20000 $MC_CHAN_NAME
By setting bit 1, the channel name stored in machine data MD20000 $MC_CHAN_NAME
can be programmed in the part program. The channel name can thus also be programmed
instead of a numerical value for the channel number in programming coordination
commands such as (START(), INIT(), WAIT() etc.
2: 0x4 reserved
3: 0x8 Convert illegal ASCII characters into blanks
By setting bit3, the previous behavior when interpreting a part program block
is
activated. This
means that all invalid ASCII characters in a part program block are
internally handled as blank.
4: 0x10 The wait time G4 F<wait time> is rounded off as a multiple integer
of an Ipo cycle.
This means that a G4 F0.001 only takes one cycle, for an Ipo cycle of 1 msec.
10284 DISPLAY_FUNCTION_MASK EXP, N01 -
- Behavior of various display variables DWORD PowerOn
-
- - 0x0 0 0x7FFFFFFF 1/1
Description: Bit mask for parameterizing various display variables:
BitNo. Hexadec. Meaning with bit set
value
Bit0: 0x1
Parameters are assigned to the OPI variable lastBlockNoStr in the SPARP and SPARPP
blocks.
Bit1: 0x2
Concerns the OPI variable cmdSpeed in the SPARPP block. If the bit is set, the variable
returns
the programmed
speed even if the spindle is at a standstill or in another mode
(positioning mode, axis mode).
Bit2 0x4
Concerns the OPI variable cmdSpeed in the SPARPP block. (reserved for constant cutting
speed)
Bit8: 0x100
Servotrace manages larger numerical values internally. Overruns in data format are
avoided. The accuracy may be reduced with large numerical values.
10368 HW_ASSIGN_DIG_FASTOUT N10 A4
- Hardware assignment of external digital NCK outputs DWORD PowerOn
-
- 4 0x01000000,
0x01000000,
0x01000000,
0x01000000,
0x01000000, 0x01...
0x01000000 0x060003FF 2/2
Machine data
3.2 General machine data
Parameter Manual
38 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
