Corresponding to ... SD41100 JOG_REV_IS_ACTIVE (JOG: Revolutional / linear feedrate)
SD42600 JOG_FEED_PER_REV_SOURCE
(control revolutional feedrate in JOG)
SD43300 ASSIGN_FEED_PER_REV_SOURCE
(revolutional feedrate for positioning axes / spindles)
MD32040 JOG_REV_VELO_RAPID (revolutional feedrate for JOG with
rapid traverse override)
MD32050 JOG_REV_VELO (revolutional feedrate for JOG)
Note for the reader Function Manual Basic Functions V1
DB3300
DBX1.3
Handwheel override active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The function "Handwheel override in AUTOMATIC mode" is active for the
programmed path axes.
Handwheel pulses of the 1st geometry axis function as a velocity override
over the programmed path feedrate.
Signal state 0 The function "Handwheel override in AUTOMATIC mode" is not active for
the programmed path axes.
An active handwheel override is not active if:
●
The path axes have reached the target position
● The distance-to-go is deleted by the channel-specific interface signal
DB21, ... DBX6.2 (delete distance-to-go)
●
A RESET is performed.
Note for the reader Function Manual Basic Functions H2
DB3300
DBX1.4
Block search active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The block search function is active. It was selected and started from the
operator interface.
Signal state 0 The block search function is not active.
Application The block search function makes it possible to jump to a certain block within
a part program and to start processing the part program from this block.
Note for the reader Function Manual Basic Functions K1
DB3300
DBX1.5
M2/M30 active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 NC block with M2 has been completely executed. If traversing motion is also pro‐
grammed in this block, the signal is only output when the target position has been
reached.
Detailed descriptions of interface signals
5.7 Channel-specific signals
Parameter Manual
394 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
