Signal state 1 When the mode changes from AUTOMATIC or MDI (in stopped program
status) to JOG, the program status changes to "interrupted". The program
can be continued at the point of interruption in AUTOMATIC or MDI mode
when "NC start" is issued.
Signal state 0 Program status interrupted is not active.
Special cases, errors, ... The IS "Program status interrupted" indicates that the part program can con‐
tinue to be processed by restarting it.
Note for the reader Function Manual Basic Functions K1
DB3300
DBX3.4
Program status aborted
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The program has been selected but not started, or the program was aborted
with a reset.
Signal state 0 Program status interrupted is not active.
Corresponding to ... IS "Reset"
Note for the reader Function Manual Basic Functions K1
DB3300
DBX3.5
Channel status active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 In this channel
●
A part program or block is presently being executed in the automatic or
MDI mode.
● At least one axis is being traversed in JOG mode
Signal state 0 "Channel status interrupted" or "Channel status reset" is active.
Note for the reader
Function Manual Basic Functions K1
DB3300
DBX3.6
Channel status interrupted
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The NC part program in AUTOMATIC or MDI can be interrupted by "NC stop",
"NC stop axes plus spindles", "NC stop at the block limit", programmed M0
or M1 or single block mode.
With an NC start, the part program or the interrupted traversing movement
can be continued.
Signal state 0 "Channel status active" or "Channel status reset" is active.
Note for the reader Function Manual Basic Functions K1
DB3300
DBX3.7
Channel status reset
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The signal is set to 1 as soon as the channel goes into the reset state, i.e. no
processing taking place.
Detailed descriptions of interface signals
5.7 Channel-specific signals
