DB3300
DBX3.0
Program status running
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The part program was started with IS "NC start" and is running.
Signal state 0
● Program stopped by M0/M1 or NC stop or mode change.
●
For single block mode, the block is executed.
● End of program reached (M2)
●
Program aborted due to a reset
● The actual block cannot be executed
Special cases, er‐
rors, ...
The IS "Program status running" does not change to 0 if workpiece machining
is stopped due to the following events:
● A feedrate disable or spindle disable was output
● IS "Read-in disable"
●
Feedrate override to 0%
● The spindle and axis monitoring functions respond
Note for the reader Function Manual Basic Functions K1
DB3300
DBX3.1
Program status wait
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The running program has come to a program command WAIT_M or WAIT_E
in an NC block. The wait condition specified in the WAIT command for the
channel or channels has not yet been fulfilled.
Signal state 0 Program status wait is not active.
Corresponding to ...
Note for the reader /PG/ Programming Manual, Fundamentals
DB3300
DBX3.2
Program status stopped
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The NC part program has been stopped by an "NC stop", "NC stop axes plus
spindles",
"NC stop
at the block limit", programmed M0 or M1 or single block
mode.
Signal state 0 Program status "stopped" is not present.
Corresponding to ... IS "NC stop"
IS "NC stop axes plus spindles"
IS "NC stop at block limit"
Note for the reader Function Manual Basic Functions K1
DB3300
DBX3.3
Program status interrupted
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.7 Channel-specific signals
Parameter Manual
396 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
