DB3300
DBX4002.5
Associated M01/M00 active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The IS is used to display that for a corresponding previous enable / activation,
an associated M00 or M01 auxiliary function is active.
Signal state 0 No associated M00/M01 auxiliary functions active.
Corresponding to ... DB3200 DBX14.5 (activate associated M01)
Note for the reader Function Manual Basic Functions K1
DB3300
DBX4002.6
Dry run feedrate active
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The dry run feedrate is active.
Instead of the programmed feedrate, the dry run feedrate entered in setting
data:
SD42100 $SC_DRY_RUN_FEED
is active.
When activated from the operator panel, the dry run feedrate signal is auto‐
matically entered in the PLC interface and transmitted by the PLC basic pro‐
gram to the PLC interface signal:
DB3200 DBX0.6 (activate dry run feedrate).
Signal state 0 Dry run feedrate is not active. The programmed feedrate is active.
Note for the reader Function Manual Basic Functions K1
DB3300
DBB4004
PROG-EVENT-DISPLAY
Signal(s) from channel (NCK → PLC)
Edge evaluation: No Signal(s) updated: Event-controlled
Signal state 1 The event assigned to the bit has activated the "Event-driven program call"
function:
Bit 0 → Part program start from channel status RESET
Bit 1 → End of part program
Bit 2 → Operator panel reset
Bit 3 → Boot
Bit 4 → 1st start after search run
Bit 5 - 7 → Reserved, currently always 0
Signal duration: At least one complete PLC cycle
Signal state 0
● The
event assigned to the bit has not activated the "Event-driven program
call" function.
● The
event-driven user program has expired or was cancelled with RESET.
Note for the reader
Detailed descriptions of interface signals
5.7 Channel-specific signals
Parameter Manual
402 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
