DB380x
DBX2002.7 and .6
Setpoint direction of rotation, counter-clockwise and clockwise
Signal(s) to axis / spindle (PLC → NCK)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
If the IS "Oscillation via the PLC" is set, then the direction of rotation for the
oscillation speed can be specified using the two IS "Setpoint direction of
rotation counter-clockwise and clockwise". The times for the oscillation
movement
of the
spindle motor are defined by setting the IS "Setpoint direc‐
tion of rotation counter-clockwise and clockwise" for a corresponding length
of time.
Signal irrelevant for ... ... spindle modes other than the oscillation mode
Application see IS "Oscillation via PLC"
Special cases, errors, ...
● If both IS are set simultaneously, no oscillation speed is output.
●
If no IS is set, then an oscillation speed is not output.
corresponding to ... IS "Oscillation via the PLC" (DB380x DBX2002.4)
IS "Oscillation speed" (DB380x DBX2002.5)
Note for the reader Function Manual Basic Functions S1
DB380x
DBB2003
Spindle override
Signal(s) to spindle (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
424 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
