Signal state 1 The spindle override is specified via the PLC in the Gray code.
The override value determines the percentage of the programmed speed
setpoint that is issued to the spindle.
Gray coding for spindle override
Switch set‐
ting
Code Spindle override factor
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
00001
00011
00010
00110
00111
00101
00100
01100
01101
01111
01110
01010
01011
01001
01000
11000
11001
11011
11010
11110
11111
11101
11100
10100
10101
10111
10110
10010
10011
10001
10000
0.5
0.55
0.60
0.65
0.70
0.75
0.80
0.85
0.90
0.95
1.00
1.05
1.10
1.15
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
1.20
corresponding to ... IS "Override active" (DB380x DBX1.7)
IS "Feedrate override for spindle valid" (DB380x DBX2001.0)
Note for the reader Function Manual Basic Functions V1
DB380x
DBX4001.0 to .2
Parameter set selection A, B, C
Signal(s) to drive (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 425
