Signal state 1 With bit combinations A, B and C, 8 different drive parameter sets can be
selected.
The following assignment applies:
Drive parameter set C B A
1
2
3
4
5
6
7
8
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
The switchable drive parameters are as follows:
●
Current setpoint filters (lowpass, bandstop); for adaptation to the
mechanic system
● Motor speed normalization
●
Speed controller parameters
● Speed setpoint filter
● Speed monitoring data
As soon as the new drive parameter becomes effective, the drive signals
this to the PLC using the interface signals:
DB390x DBX4001.0 to 2 (active drive parameter set).
Application Drive parameter switchover can be used, for example, for the following:
● To change the gear stage
● To change over the measuring circuit
Special cases, errors, ...
In principle it is possible to switch over drive parameter sets at any time.
However, as torque
jumps can occur when switching over speed controller
parameters and motor speed normalization, parameters should only be
switched over when stationary at zero speed (especially when the axis is
stationary).
corresponding to ... DB390x DBX4001.0 to 2 (active parameter set)
Note for the reader Commissioning Manual, Turning and Milling
DB380x
DBX4001.6
Speed controller integrator disable
Signal(s) to drive (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 For the drive, the interface signal is used to disable the speed controller
integrator. The speed controller is thus changed over from a PI to a P con‐
troller.
Note:
If the speed controller integrator disable is activated, compensation opera‐
tions might take place in certain applications (e.g. if the integrator was al‐
ready holding a load while stationary).
The drive acknowledges the integrator disable:
DB390x DBX4001.6 (speed controller integrator disabled)
Signal state 0 The integrator of the speed controller is enabled.
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
426 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
