10707 PROG_TEST_MASK N01 K1
- Program test mode DWORD PowerOn
-
808d-me42 - 0x1 0 0x1B 1/1
808d-me62 - 0x1 0 0x1B 1/1
808d-te42 - 0x1 0 0x1B 1/1
808d-te62 - 0x1 0 0x1B 1/1
808d-mte40 - 0x11 0 0x1F 1/1
808d-mte60 - 0x11 0 0x1F 1/1
Description: Bit-coded mask for program test
Bit 0 == 1 Program test cannot be deselected in 'Stopped' program status.
Bit 1 == 1 Enable to activate the program test using the PI command _N_NCKMOD
Bit 2 == 1 Activation of program test with accelerated feed in normal program
processing. If the bit is set, the program test is active in all channels with
accelerated
feed via the VDI signal in the first channel. The VDI signal has no effect
in all other channels as long as the bit is set. The value in $MC_SERUPRO_SPEED_FACTOR
of the first channel is used as the feed. Only released for test purposes.
Bit 3 == 1 Activation of program test with accelerated feed in the simulation.
Bit 4 == 1 Activation of accelerated program test takes place in synchronized multi-
channel mode.
Bit 5..31 As yet unused.
Program test with normal processing is always activated via the VDI interface.
Program test in simulation is always activated via the NCKMode PI.
Program test block search is always activated via the Find-Pi.
10709 PROG_SD_POWERON_INIT_TAB EXP, N01 K1
- Setting data to be initialized DWORD PowerOn
-
- 30 43200, 43202, 0, 0, 0,
0, 0, 0...
- - 2/2
Description: Setting data to be initialized:
The values of the programmable SD indicated in this MD are set to their initial values
on control power up.
Only the setting data listed in the table below, however, can be initialized. If
invalid
setting data
numbers are configured, then the alarm 4009 is output at the next
run-up of the control. The alarm shows the index used for configuring the invalid
setting data. The alarm can only be eliminated by changing the invalid setting data,
i.e. by entering either a valid number or zero!
(GCODE)
SD42000 $SC_THREAD_START_ANGLE SF
SD42010 $SC_THREAD_RAMP_DISP DITS/DITE
SD42125 $SC_SERUPRO_SYNC_MASK
SD42400 $SC_PUNCH_DWELLTIME PDELAYON
SD42402 $SC_NIBPUNCH_PRE_START_TIME
SD42404 $SC_MINTIME_BETWEEN_STROKES
SD42800 $SC_SPIND_ASSIGN_TAB SETMS
SD43200 $SA_SPIND_S S wih G94,G95,G97,G971,G972
SD43202 $SA_SPIND_CONSTCUT_S S with G96,G961,G962
SD43210 $SA_SPIND_MIN_VELO_G25 G25 S
SD43220 $SA_SPIND_MAX_VELO_G26 G26 S
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 43
