SD43230 $SA_SPIND_MAX_VELO_LIMS LIMS
SD43235 $SA_SPIND_USER_VELO_LIMIT
SD43300 $SA_ASSIGN_FEED_PER_REV_SOURCE FPRAON
SD43350 $SA_AA_OFF_LIMIT
SD43420 $SA_WORKAREA_LIMIT_PLUS G26
SD43430 $SA_WORKAREA_LIMIT_MINUS G25
SD43600 $SA_IPOBRAKE_BLOCK_EXCHANGE
SD43610 $SA_ADISPOSA_VALUE
SD43700 $SA_OSCILL_REVERSE_POS1 OSP1
SD43710 $SA_OSCILL_REVERSE_POS2 OSP2
SD43720 $SA_OSCILL_DWELL_TIME1 OST1
SD43730 $SA_OSCILL_DWELL_TIME2 OST2
SD43740 $SA_OSCILL_VELO FA
SD43750 $SA_OSCILL_NUM_SPARK_CYCLES OSNSC
SD43760 $SA_OSCILL_END_POS OSE
SD43770 $SA_OSCILL_CTRL_MASK OSCTRL
SD43780 $SA_OSCILL_IS_ACTIVE OS
SD43790 $SA_OSCILL_START_POS
10710 PROG_SD_RESET_SAVE_TAB EXP, N01 A3, V1
- Setting data to be updated DWORD PowerOn
-
- 30 0, 0, 0, 0, 0, 0, 0, 0... - - 2/2
Description: Setting data to be backed up
The values of the SDs listed in this table are stored in non-volatile memory, i.e. they
remain valid after power ON. The setting data whose HMI numbers were entered in the
backup list are written into the (buffered) active file system after the description
of the part program on reset.
Programmable setting data are:
(GCODE)
SD 42000 $SC_THREAD_START_ANGLE SF
SD 42010: $SC_THREAD_RAMP_DISP DITS/DITE
SD 42400 $SC_PUNCH_DWELLTIME PDELAYON
SD 42800 $SC_SPIND_ASSIGN_TAB SETMS
SD 43200: $SA_SPIND_S S with G94,G95,G97,G971,G972
SD 43202: $SA_SPIND_CONSTCUT_S S with G96,G961,G962
SD 43210 $SA_SPIND_MIN_VELO_G25 G25S
SD 43220 $SA_SPIND_MAX_VELO_G26 G26 S
SD 43230 $SA_SPIND_MAX_VELO_LIMS LIMS
SD 43300 $SA_ASSIGN_FEED_PER_REV_SOURCE FPRAON
SD 43420 $SA_WORKAREA_LIMIT_PLUS G26
SD 43430 $SA_WORKAREA_LIMIT_MINUS G25
SD 43700 $SA_OSCILL_REVERSE_POS1 OSP1
SD 43710 $SA_OSCILL_REVERSE_POS2 OSP2
SD 43720 $SA_OSCILL_DWELL_TIME1 OST1
SD 43730 $SA_OSCILL_DWELL_TIME2 OST2
SD 43740 $SA_OSCILL_VELO FA
SD 43750 $SA_OSCILL_NUM_SPARK_CYCLES OSNSC
SD 43760 $SA_OSCILL_END_POS OSE
Machine data
3.2 General machine data
Parameter Manual
44 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
