DB390x
DBX4.7 and .6
Plus and minus travel command
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 Travel is to be executed in the axis direction involved. Depending on the
mode selected, the travel command is triggered in different ways.
●
JOG mode: With the plus or minus traversing key
● Under
REF mode: With traversing key that takes the axis to the reference
point
● AUTO/MDI mode: A program block containing a coordinate value for the
axis in question is executed.
Signal state 0 A travel command in the relevant axis direction has not been given or a
traverse movement has been completed.
● JOG mode:
– Withdrawing the traversing key.
–
When ending traversing with the handwheel.
– Under REF mode: When the reference point is reached
● AUTO/MDI mode:
– The program block has been executed (and the next block does not
contain any coordinate values for the axis in question)
– Cancel using "RESET", etc.
– IS "Axis disable" is active
Application To release clamped axes (e.g. on a rotary table).
Note:
If the clamping
is not released until the travel command is given, these axes
cannot be operated under continuous path control!
corresponding to ... IS "Traversing key plus" and "Traversing key minus" (DB380x DBX4.7 and .
6)
Note for the reader Function Manual Basic Functions H1
DB390x
DBX5.0 to .6
Active machine function 1 INC, ..., continuous
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The PLC interface receives a signal stating which JOG mode machine func‐
tion is active for the machine axes.
Signal state 0 The machine function in question is not active.
corresponding to ... IS "Machine function 1 INC, ..., continuous" (DB380x DBX5.0 ... .6)
Note for the reader Function Manual Basic Functions H1
DB390x
DBX1002.0
Lubrication pulse
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 435
