Edge change 0 → 1 or 1
→ 0
As soon as the axis / spindle has traveled through the distance set in
MD33050, the "lubrication
pulse" interface signal is inverted and lubrication
is started.
The position measurement is restarted after each Power On.
Application The lubrication pump for the axis / spindle can be activated with IS "Lubrica‐
tion pulse". Machine
bed lubrication therefore depends on the distance trav‐
eled.
corresponding to ... MD33050 LUBRICATION_DIST (lubrication pulse distance)
Note for the reader Function Manual Basic Functions A2
DB390x
DBX1002.4
Path axis
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The axis is involved in the path (path axis).
Signal state 0 The axis is not involved in the path.
Note for the reader Function Manuals
DB390x
DBX1002.5
Positioning axis
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The NCK handles the axis as positioning axis. This means that it has:
●
its own axis interpolator (linear interpolator)
● its own feedrate (F value)
●
its own feedrate override
● exact stop (G09) at the progr. end position
Signal state 0 The axis is not a positioning axis.
Note for the reader Function Manual, Expansion Functions P2
DB390x
DBX1002.6
Indexing axis in position
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The signal is dependent on "Exact stop fine":
The signal is set if "Exact stop fine" is reached. The signal is reset when
exiting "Exact stop fine".
●
The indexing axis is located on an indexing position.
●
The indexing axis has been positioned with instructions for "Coded
Position".
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
Parameter Manual
436 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
