DB390x
DBX2002.6
Active spindle mode oscillation mode
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The spindle is in the oscillation mode if a new gear stage was defined using
the
automatic gear
stage selection (M40) or using M41 to M45 (IS "Change
gear stage" is set). The IS "Change gear stage" is only set if a new gear
stage is defined that is not the same as the actual gear stage.
corresponding to ... IS "Active spindle control mode" (DB390x DBX2002.7)
IS "Active spindle positioning mode" (DB390x DBX2002.5)
IS "Change gear stage" (DB390x DBX2000.3)
Note for the reader Function Manual Basic Functions S1
DB390x
DBX2002.7
Active spindle control mode
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
With the following function, the spindle is in the control mode:
Spindle direction of rotation input M3/M4 or spindle stop M5
corresponding to ... IS "Active spindle oscillating mode" (DB390x DBX2002.6)
IS "Active spindle positioning mode" (DB390x DBX2002.5)
Note for the reader Function Manual Basic Functions S1
DB390x
DBX2003.5
Spindle in position
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: Yes Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Precondition for the output of IS "Spindle in position" is reaching the IS "Exact
stop
fine". Additionally,
the last programmed spindle position must have been
reached on the setpoint side.
If the spindle is already at the programmed position after a positioning, then
the signal "Spindle in position" is set.
Signal state 0 or edge
change 1 → 0
The IS "Spindle in position" is always reset when withdrawing IS "Exact stop
fine".
Application The interface signal is processed exclusively with the function spindle posi‐
tioning. This includes:
●
SPOS, SPOSA and M19 in the part program
● SPOS and M19 in synchronized actions
Spindle in position for the tool change.
If the tool change cycle is interrupted by the machine operator e.g. with NC
stop,
NC stop axis plus spindle, mode stop etc., then the correct position to
which the spindle is to travel in the tool changer can be queried using the IS
"Spindle in position".
Special cases, errors, ... If the spindle is traversed after a positioning for already set "Spindle in posi‐
tion" signal, e.g. in the JOG mode, then this signal is deleted. If the spindle
returns to its original position in the JOG mode, then the signal "Spindle in
position" is set again. The last position selection is maintained.
corresponding to ... DB390x DBX0.7 (exact stop fine)
Note for the reader Function Manual Basic Functions S1
Detailed descriptions of interface signals
5.8 Axis / spindle-specific signals
