1 Activate
program
test
Enable pro‐
tection
zones
Activate ref‐
erencing
2 Activate skip block
7 6 5 4 3 2 1 0
3
4 Feedrate offset
2)
H G F E D C B A
5 Rapid traverse override
H G F E D C B A
6 Feedrate
override ac‐
tive
3)
Rapid tra‐
verse over‐
ride active
Path veloci‐
ty limiting
Program
level abort
Delete
number of
subroutine
cycles
Delete dis‐
tance -to-go
Read-in dis‐
able
Federate
disable
7 Suppress
start lock
NC stop ax‐
es plus
spindle
NC stop NC stop at
block limit
NC start NC start
disable
8 Activate machine-related protection zone
Area 8 Area 7 Area 6 Area 5 Area 4 Area 3 Area 2 Area 1
9 Activate machine-related protection zone
Area 10 Area 9
10 Activate channel-specific protection zone
Area 5 Area 5 Area 5 Area 5 Area 5 Area 5 Area 5 Area 5
11 Activate channel-specific protection zone
Area 10 Area 9
12
13 Do not
block tool
Deactivate
workpiece
counter
Activate fixed feedrate
Feed 4 Feed 3 Feed 2 Feed 1
14 No tool
change
commands
JOG circle Activate as‐
sociated
M01
Negative di‐
rection for
simulation
contour
handwheel
Simulation
contour
handwheel
ON
Activate contour handwheel (bit/binary
coded)
Handwheel
1
Handwheel
2
15 Activate
skip block 9
Activate
skip block 8
Invert con‐
tour hand‐
wheel
direc‐
tion
16 Program
branches
(GOTOS)
control
17
18
19
1)
Select single-block type selection using the softkey.
2)
31 positions (Gray code)
PLC user interface
6.8 Channel signals
Parameter Manual
470 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
