Siemens SINUMERIK 808D ADVANCED

Controls signals to axes in Work
DB3200 Signals to NCK channel [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
1000 Axis 1 in Work
Traversing keys Rapid tra‐
verse over‐
ride
Traversing
key dis‐
tance disa‐
ble
Feedrate
stop
Activate handwheel (bit/binary coded)
1)
Plus Minus 2 1
1001 Axis 1 in Work
Machine function
2)
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
1002
1003
Handwheel
direction of
rotation in‐
verted
1004 Axis 2 in Work
Traversing keys Rapid tra‐
vers over‐
ride
Traversing
key disable
Feedrate
stop
Activate handwheel (bit/binary coded)
Plus Minus 2 1
1005 Axis 2 in Work
Machine function
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
1006
1007
Invert hand‐
wheel
direc‐
tion
1008 Axis 3 in Work
Traversing keys Rapid tra‐
verse over‐
ride
Traversing
key disable
Feedrate
stop
Activate handwheel (bit/binary coded)
Plus
Minus 2 1
1009 Axis 3 in Work
Machine function
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
1010
1011 Invert hand‐
wheel
direc‐
tion
1)
The handwheel number
is represented according to the $MD_HANDWH_VDI_REPRESENTATION machine data in a bit-
coded (=0) or binary-coded (=1) manner.
PLC user interface
6.8 Channel signals
