10719 T_NO_FCT_CYCLE_MODE EXP, N12, N07 K1
- Setting of T function substitution DWORD PowerOn
-
- - 0 0 0x7 2/2
Description: This machine data parameterizes the execution of the replacement subprogram for the
tool and tool offset selection.
Bit 0 = 0:
D or DL number is transferred to the replacement subprogram (default value)
Bit 0 = 1:
The D or DL number is not transferred to the replacement subprogram if the following
conditions are fulfilled: MD22550 $MC_TOOL_CHANGE_MODE = 1 Programming D/DL with T
or M function with which the tool change cycle is called, in a part program line.
Bit 1 = 0
Execution of the replacement subprogram at end of block (default value)
Bit 1 = 1
Execution of the replacement subprogram at block start
Bit 2 = 0:
Execution of the replacement subprogram according to the settin of bit 1
Bit 2 = 1:
Execution of the replacement subprogram at block start and at end of block.
10720 OPERATING_MODE_DEFAULT N01 H2
- Setting of mode after power ON BYTE PowerOn
-
- 1 7, 7, 7, 7, 7, 7, 7, 7... 0 12 1/1
Description: Default modes of the mode groups after power ON.
If no mode is selected by the PLC, all the channels associated with mode group n are
in the mode preset by OPERATING_MODE_DEFAULT[ n -1 ] after power ON:
0 = Automatic mode
1 = Automatic mode, submode REPOS
2 = MDI mode
3 = MDI mode, submode REPOS
5 = MDI mode, submode Reference point approach
6 = JOG mode
7 = JOG mode, submode Reference point approach
NOTICE! Depending on the machine data MD10721 $MN_OPERATING_MODE_EXTENDED, the mode
set here might not be adopted after power ON
10721 OPERATING_MODE_EXTENDED N01 H2
- Extended setting of mode after power ON BYTE PowerOn
-
- 1 0, 0, 0, 0, 0, 0, 0, 0... 0 1 1/1
Description: Extended setting of an operating mode of the operating mode groups after power on:
0 = Selection of the operating mode according to MD10720 $MN_OPERATING_MODE_DEFAULT
1 = Selection of the JOG mode if the PLC signal "Retract data available"
(DB3300.DBX4005.5) is set in at least one channel of the operating mode group
Machine data
3.2 General machine data
Parameter Manual
48 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
