10724 NC_SYS_CODE_CONF_NAME_TAB EXP, N01 TE1, B1
- List of internal NC codes STRING PowerOn
-
- 20 - - - ReadOnly
Description: Identifier list of internal NC codes
Reserved for internal applications
10735 JOG_MODE_MASK EXP, N01 K1
- Settings for JOG mode DWORD PowerOn
-
- - 0 0 0x1ff 2/2
Description: Bit 0:
Enables JOG in automatic.
JOG is enabled in automatic when all channels in the mode group are in the RESET state
and no channel of the DRF mode group has been selected. The mode group changes
internally to JOG with the +/- key and the handwheel, and the axis moves. After the
JOG motion has ended, a change back to AUTO is also made internally.
Bit 1:
Position with AxFrame.
The function 'JOG to position' considers all axial frames and, in the case of an axis
configured as geometry axis, the tool length offset.
Bit 2:
Travel in opposite direction.
The functions 'JOG to position' and 'Approach machine fixed point manually' allow
travel in opposite direction, i.e. away from the specified position.
Bit 3:
Tool radius offset.
MD21020 $MC_WORKAREA_WITH_TOOL_RADIUS is active with JOG motions of the geometry axes.
Bit 4:
Alarm suppression operating range limit in the basic coordinate system in JOG.
Alarms that would be output in JOG when an operating range limit is reached in the
basic coordinate system, are suppressed.
Bit 5:
Alarm suppression operating range limit in the workpiece coordinate system in JOG.
Alarms that would be output in JOG when an operating range limit is reached in the
workpiece coordinate system, are suppressed.
Bit 6, 7:
JOG of circles:
Bit 7 and bit 6 = 0: traversing the 2nd geometry axis of the active plane to PLUS for
radius increase, traversing to MINUS for radius decrease independently of inner or
outer machining being active.
Bit 7 = 1 and bit 6 = 0: traversing the 2nd geometry axis of the active plane to PLUS
always
travels in
the direction of the limiting circle. This means that the radius is
increased on inner machining and decreased on outer machining.
Bit 7 = 1 and bit 6 = 1: traversing the 2nd geometry axis of the active plane to MINUS
always travels in
the direction of the limiting circle. This means that the radius is
increased on inner machining and decreased on outer machining.
Bit 8:
Bit 8 = 0 If there is a JOG retract movement, the retraction axis can only be jogged
in the plus direction.
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 49
