Bit 8 = 1 If there is a JOG retract movement, the retraction axis can only be jogged
in the plus and minus direction.
Bits 9-31:
Currently unassigned.
10760 G53_TOOLCORR N12 FBFA
- Method of operation of G53, G153 and SUPA DWORD NEW CONF
-
- - 0 0 0x3 2/2
Description: With this MD you define whether tool length offset and tool radius offset are also to
be suppressed with language commands G53, G153 and SUPA
The machine data is bit-coded.
Bit 0 = 0: G53, G153 and SUPA cause block-by-block suppression of work offsets. The
active tool length offset and tool radius offset remain active.
Bit 0 = 1: G53, G153 and SUPA cause block-by-block suppression of work offsets, active
tool length offset and tool radius offset. The tool length behavior can be modified
with bit 1.
Bit 1 is only evaluated, if the value of bit 0 is 1.
Bit1 = 0: with bit 0 set, the tool length is always suppressed with G53, G153 and SUPA.
Bit1 = 1: with bit 0 set the tool length is only suppressed with G53, G153 and SUPA,
if
a cutting
edge is not selected in the same block (this can also be the cutting edge
that is already active).
10808 EXTERN_INTERRUPT_BITS_M96 EXP, N12 FBFA
- Activate interrupt program (ASUB) DWORD PowerOn
-
- - 0 0 0x7FFFFFFF 1/1
Description: Setting the various bits can influence the processing of the interrupt routine
activated by M96 P...
Bit 0 = 0,
No interrupt program possible, M96/M97 are normal M functions
Bit 0 = 1,
Using M96/M97 to activate an interrupt program is allowed
Bit 1 = 0,
Continue processing part program at the final position of the next block after the
interrupt block
Bit 1 = 1,
Continue processing part program from interrupt position
Bit 2 = 0,
The interrupt signal immediately interrupts the current block and starts the interrupt
routine
Bit 2 = 1,
The interrupt routine will not be started until the end of the block
Bit 3 = 0,
Interrupt machining cycle at an interupt signal
Bit 3 = 1,
Do not start interrupt program until the end of a machining cycle.
Machine data
3.2 General machine data
Parameter Manual
50 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
