Siemens SINUMERIK 808D ADVANCED Parameter Manual

11350 HANDWHEEL_SEGMENT N09 H1
- Handwheel segment BYTE PowerOn
-
808d-me42 6 2, 2, 0, 0, 0, 0 0 - ReadOnly
808d-me62 6 2, 2, 0, 0, 0, 0 0 - ReadOnly
808d-te42 6 2, 2, 0, 0, 0, 0 0 - ReadOnly
808d-te62 6 2, 2, 0, 0, 0, 0 0 - ReadOnly
808d-mte40 6 2, 2, 0, 0, 0, 0 0 - 7/2
808d-mte60 6 2, 2, 0, 0, 0, 0 0 - 7/2
Description: Machine data defines which
hardware segment the handwheel is connected to:
0 = SEGMENT_EMPTY ;no handwheel
1 = SEGMENT_840D_HW ;handwheel at 840D HW
2 = SEGMENT_8xxD_HW ;handwheel at 828D sl, 808D -HW
5 = SEGMENT_PROFIBUS ;handwheel at PROFIBUS
7 = SEGMENT_ETHERNET ;handwheel at Ethernet
11351 HANDWHEEL_MODULE N09 H1
- Handwheel module BYTE PowerOn
-
808d-me42 6 1, 1, 0, 0, 0, 0 0 6 ReadOnly
808d-me62 6 1, 1, 0, 0, 0, 0 0 6 ReadOnly
808d-te42 6 1, 1, 0, 0, 0, 0 0 6 ReadOnly
808d-te62 6 1, 1, 0, 0, 0, 0 0 6 ReadOnly
808d-mte40 6 1, 1, 0, 0, 0, 0 0 6 7/2
808d-mte60 6 1, 1, 0, 0, 0, 0 0 6 7/2
Description: Machine data specifies the hardware module to which
the handwheel is connected.
(Content dependent on MD11350 $MN_HANDWHEEL_SEGMENT):
0 = no handwheel configured
MD11351 $MN_HANDWHEEL_MODUL =
1 ;SEGMENT_840D_HW
1 ;SEGMENT_8xxD_HW; 828D sl, 808D -HW
1..6 ;SEGMENT_PROFIBUS/PROFINET ;index for MD11353
$MN_HANDWHEEL_LOGIC_ADDRESS[(x-1)]
1 ;SEGMENT_ETHERNET
11352 HANDWHEEL_INPUT N09 H1
- Handwheel connection BYTE PowerOn
-
808d-me42 6 1, 2, 0, 0, 0, 0 0 6 ReadOnly
808d-me62 6 1, 2, 0, 0, 0, 0 0 6 ReadOnly
808d-te42 6 1, 2, 0, 0, 0, 0 0 6 ReadOnly
808d-te62 6 1, 2, 0, 0, 0, 0 0 6 ReadOnly
808d-mte40 6 1, 2, 0, 0, 0, 0 0 6 7/2
808d-mte60 6 1, 2, 0, 0, 0, 0 0 6 7/2
Description: Machine data which is intended to select
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 69
