Siemens SINUMERIK 808D ADVANCED Parameter Manual

12986 PLC_DEACT_IMAGE_LADDR_IN N10 -
- Deactivation of I/O connection to the PLC image DWORD PowerOn
-
808d-me42 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 ReadOnly
808d-me62 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 1/1
808d-te42 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 ReadOnly
808d-te62 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 1/1
808d-mte40 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 1/1
808d-mte60 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 1/1
Description: The PLC input/output image of the stations with these logical addresses
is not connected to the real I/Os
12987 PLC_DEACT_IMAGE_LADDR_OUT N10 -
- Deactivation of I/O connection to the PLC image DWORD PowerOn
-
808d-me42 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 ReadOnly
808d-me62 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 1/1
808d-te42 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 ReadOnly
808d-te62 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 1/1
808d-mte40 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 1/1
808d-mte60 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 1/1
Description: The PLC input/output image of the stations with these logical addresses
is not connected to the real I/Os
13080 DRIVE_TYPE_DP EXP G2
- PROFIBUS/PROFINET drive type BYTE PowerOn
-
808d-me42 31 0, 0, 0, 0, 0, 0, 0, 0... 0 5 ReadOnly
808d-me62 31 0, 0, 0, 0, 0, 0, 0, 0... 0 5 ReadOnly
808d-te42 31 0, 0, 0, 0, 0, 0, 0, 0... 0 5 ReadOnly
808d-te62 31 0, 0, 0, 0, 0, 0, 0, 0... 0 5 ReadOnly
808d-mte40 31 0, 0, 0, 0, 0, 0, 0, 0... 0 5 7/2
808d-mte60 31 0, 0, 0, 0, 0, 0, 0, 0... 0 5 7/2
Description: MD is relevant to PROFIdrive drives at the PROFIBUS/PROFINET:
Drive type:
0: No drive or drive type unknown (default),
software-internally treated as:
1: FDD drive (SRM: Synchronous rotary drive)
Machine data
3.2 General machine data
Parameter Manual
78 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
