2: MSD drive (ARM: Asynchronous rotary drive)
3: Linear drive
4: Analog drive (no automatic entry)
5: Hydraulic drive
Note:
In general, the drive type is entered automatically with Siemens drives as soon as the
drives start operating.
With non-Siemens drives (at least with linear drives), the value must be entered
manually if automatic drive recognition is not possible.
13110 PROFIBUS_TRACE_ADDRESS EXP -
- PROFIBUS/PROFINET trace of I/O slots DWORD NEW CONF
-
808d-me42 14 0, 0, 0, 0, 0, 0, 0, 0... 0 - 0/0
808d-me62 14 0, 0, 0, 0, 0, 0, 0, 0... 0 - 1/1
808d-te42 14 0, 0, 0, 0, 0, 0, 0, 0... 0 - 0/0
808d-te62 14 0, 0, 0, 0, 0, 0, 0, 0... 0 - 1/1
808d-mte40 14 0, 0, 0, 0, 0, 0, 0, 0... 0 - 2/2
808d-mte60 14 0, 0, 0, 0, 0, 0, 0, 0... 0 - 2/2
Description: For PROFIBUS/PROFINET only:
Logical I/O address that is to be recorded.
13111 PROFIBUS_TRACE_TYPE EXP -
- PROFIBUS/PROFINET trace settings DWORD NEW CONF
-
808d-me42 - 0 0 3 0/0
808d-me62 - 0 0 3 1/1
808d-te42 - 0 0 3 0/0
808d-te62 - 0 0 3 1/1
808d-mte40 - 0 0 3 2/2
808d-mte60 - 0 0 3 2/2
Description: For PROFIBUS/PROFINET only:
0: Recording to the part program memory /_N_MPF_DIR/_N_SIEMDPTRC_MPF
1: Recording to mass storage /user/sinumerik/data/temp/siemdptrc.trc
2: Recording to the part program memory with runtime measurement
3: Recording of cyclic PN-NCULINK communication
13112 PROFIBUS_TRACE_FILE_SIZE EXP -
- Maximum trace file size in kbytes DWORD NEW CONF
-
808d-me42 - 40 - - 0/0
808d-me62 - 40 - - 1/1
808d-te42 - 40 - - 0/0
808d-te62 - 40 - - 1/1
808d-mte40 - 40 - - 2/2
808d-mte60 - 40 - - 2/2
Description: For PROFIBUS/PROFINET only:
0: Trace without file size limitation
>0: Trace with file size limitation
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 79
