13113 PROFIBUS_TRACE_START EXP -
- Activation of PROFIBUS/PROFINET trace DWORD Immediately
-
808d-me42 - 0 0 1 0/0
808d-me62 - 0 0 1 1/1
808d-te42 - 0 0 1 0/0
808d-te62 - 0 0 1 1/1
808d-mte40 - 0 0 1 2/2
808d-mte60 - 0 0 1 2/2
Description: For PROFIBUS/PROFINET only:
0: Trace off
1: Trace on
MD13112 $MN_PROFIBUS_TRACE_FILE_SIZE > 0: Trace is automatically disabled when the
file size is reached.
13114 PROFIBUS_TRACE_START_EVENT EXP -
- Trigger conditions for PROFIBUS/PROFINET trace DWORD NEW CONF
-
808d-me42 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 0/0
808d-me62 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 1/1
808d-te42 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 0/0
808d-te62 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 1/1
808d-mte40 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 2/2
808d-mte60 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 2/2
Description: For PROFIBUS/PROFINET only:
The trigger frequency is configured bit-by-bit
Bits 0-15: 0x0001-0xffff: bit mask
Bits 16-23: 0x01-0x14: process data number (a maximum of 20 words are permissible)
Bits 24-27:0x01: status change 0->1
0x00: status change 1->0
Bits 28-31:0x10: send slot
0x00: receive slot
When MD13113 $MN_PROFIBUS_TRACE_START=1 and MD13114
$MN_PROFIBUS_TRACE_START_EVENT=0x0 Recording starts immediately
When MD13113 $MN_PROFIBUS_TRACE_START=1 and MD13114
$MN_PROFIBUS_TRACE_START_EVENT=0x1 Recording starts on control power on
When MD13113 $MN_PROFIBUS_TRACE_START=1 and MD13114
$MN_PROFIBUS_TRACE_START_EVENT=0x2 Recording starts on loss of the sign of life
13120 CONTROL_UNIT_LOGIC_ADDRESS N04, N10 -
- Logical address of SINAMICS CU DWORD PowerOn
-
808d-me42 1 6500, 0, 0, 0, 0, 0, 0, 0... 0 16383 7/2
808d-me62 5 0 0 8191 0/2
808d-te42 1 6500, 0, 0, 0, 0, 0, 0, 0... 0 16383 7/2
808d-te62 5 0 0 8191 0/2
808d-mte40 15 6500, 0, 0, 0, 0, 0, 0, 0... 0 16383 7/2
808d-mte60 15 0 0 8191 0/2
Machine data
3.2 General machine data
Parameter Manual
80 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
