Description: For PROFIBUS/PROFINET, SINAMICS:
Logical I/O address of a SINAMICS-CU (Control Unit) on the PROFIBUS/PROFINET.
The cyclic DP communication with SINAMICS-CU is activated by taking over the
associated slot address from the STEP7 project. The onboard I/Os cannot be accessed
until after configuration.
13150 SINAMICS_ALARM_MASK N04, N05 -
- Activate fault and warning buffer output for Sinamics DWORD Immediately
-
808d-me42 - 0x0 0 0x7FFFFFFF ReadOnly
808d-me62 - 0x0 0 0x7FFFFFFF ReadOnly
808d-te42 - 0x0 0 0x7FFFFFFF ReadOnly
808d-te62 - 0x0 0 0x7FFFFFFF ReadOnly
808d-mte40 - 0x0 0 0x7FFFFFFF 7/2
808d-mte60 - 0x0 0 0x7FFFFFFF 7/2
Description: For PROFIBUS/PROFINET only, especially SINAMICS:
Relevant to SINAMICS diagnostics:
Note: the effect of this MD may be hidden independently of
the value of MD13140 $MN_PROFIBUS_ALARM_ACCESS.
Mask for displaying the SINAMICS DOS fault and warning buffers
Bit set: Alarms in this DO group are output
Bit not set: Alarms in this DO group are not output
Bit Hex. Meaning
value
====================================================================================
0: 0x1 Output faults of the Control Units
1: 0x2 Reserved
2: 0x4 Output faults of the Drive Controls
3: 0x8 Output faults of the Line Modules
4: 0x10 Output faults of the Terminal Boards
5: 0x20 Output faults of the Terminal Modules
8: 0x100 Output warnings of the Control Units
9: 0x200 Output warnings of the Communication Objects
10: 0x400 Output warnings of the Drive Controls
11: 0x800 Output warnings of the Line Modules
12: 0x1000 Ouptut warnings of the Terminal Boards
13: 0x2000 Output warnings of the Terminal Modules
13160 SINAMICS_MAX_SLAVE_ADDRESS N04, N10 -
- Highest SINAMICS slave address DWORD PowerOn
-
808d-me42 4 0, 0, 0, 0 0 - ReadOnly
808d-me62 4 0, 0, 0, 0 0 - ReadOnly
808d-te42 4 0, 0, 0, 0 0 - ReadOnly
808d-te62 4 0, 0, 0, 0 0 - ReadOnly
808d-mte40 4 0, 0, 0, 0 0 - 7/2
808d-mte60 4 0, 0, 0, 0 0 - 7/2
Description: Highest slave/device address supported per bus
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 81
