All slaves/devices with an address higher than the address set here are ignored by the
NCK
Value 0: No limitation
13200 MEAS_PROBE_LOW_ACTIVE N10, N09 M5
- Polarity reversal of sensor BOOLEAN PowerOn
-
- 2 FALSE, FALSE 0 - 3/3
Description: This MD defines the electrical polarity of each connected sensor.
Value 0:
(Default setting)
Non-deflected state 0 V
Deflected state 24 V
Value 1:
Non-deflected state 24 V
Deflected state 0 V
The programmed edges of the sensor are independent of the electrical polarity, and are
to be regarded as purely mechanical. The programming of a positive edge always means
the transition from the non-deflected into the deflected state. The programming of a
negative edge always means the transition from the deflected into the non-deflected
state.
13220 MEAS_PROBE_DELAY_TIME N10, N09 FBA
s Delay time between probe deflection and recognition DOUBLE PowerOn
-
- 2 0.0, 0.0 0 0.1 3/3
Description: For probes with e.g. radio transmission, the probe deflection can be detected in the
NC only with delay.
With this MD, the transmission link delay between the probe deflection and its
detection is set in the control.
The measured value is corrected internally by the control by the distance that
corresponds to the traversing motion during this time before measuring (modeling).
It is practicable to set values only up to a maximum of 15 position controller cycles.
Anyhow, the modeling could not work with the expected accuracy with values greater
than that. In this case, the input value is therefore limited internally by the
software to 15 position controller cycles (without any further feedback).
13230 MEAS_PROBE_SOURCE N10, N09 -
- Probe simulation BYTE PowerOn
-
- - 0 0 9 3/2
Description: Simulation of the probe only works when all axes are simulated.
Value = 0: the probe is triggered on the programmed end position.
Value = 1-8: the probe is triggered via digital output with the number=value.
Value = 9: reserved
13231 MEAS_PROBE_OFFSET N10, N09 -
mm/inch,
degrees
Probe offset DOUBLE Immediately
-
- - 0.1 - - 7/7
Machine data
3.2 General machine data
Parameter Manual
82 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
