Description: The switching position of the probe is offset by the value.
The offset is only active with the simulated probes and MD 13230
$MN_MEAS_PROBE_SOURCE=0.
14510 USER_DATA_INT N03 P3
- User data (INT) DWORD PowerOn
-
- 32 0, 0, 0, 0, 0, 0, 0, 0... -32768 32767 7/3
Description: User data is stored in the NCK-PLC interface, and can be read by the PLC user from the
DB20 during the runup.
14512 USER_DATA_HEX N03 P3
- User data (HEX) DWORD PowerOn
-
- 32 0, 0, 0, 0, 0, 0, 0, 0... 0 0x0FF 7/3
Description: User data is stored in the NCK-PLC interface and can be read by the PLC user from the
DB20 during the PLC runup.
14514 USER_DATA_FLOAT N03 P3
- User data (FLOAT) DOUBLE PowerOn
-
- 8 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
-3.40e38 3.40e38 7/3
Description: User data is stored in the NCK-PLC interface, and can be read by the PLC user from the
DB20 during the runup.
14516 USER_DATA_PLC_ALARM N03 A2, P3
- User data (HEX) BYTE PowerOn
-
- 128 0, 0, 0, 0, 0, 0, 0, 0... 0 - 7/3
Description: Configuration of alarm responses to user PLC alarms
Bit 0 NC start disabled
Bit 1 Read-in disable
Bit 2 Feed disable for all axes
Bit 3 EMERGENCY STOP
Bit 4 PLC in stop
Bit 5 Alarm log
Bit 6 Definition for alarm or message (1: Alarm, 0: Message
Bit 7 Delete at POWER ON
15700 LANG_SUB_NAME N01 K1
- Name for substitution subroutine STRING PowerOn
-
- - - - - 2/2
Description: Name of the user program called on the basis of a substitution configured by MD30465
$MA_AXIS_LANG_SUB_MASK.
The user program is called with the path configured by MD15702 $MN_LANG_SUB_PATH.
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 83
