The value = -1 means that the number of resulting offsets is equal to the number of
cutting edges multiplied by the number of resulting offsets per cutting edge.
A value > 0 and < "number of cutting edges multiplied by the number of resulting
offsets per cutting edge" means that a maximum "number of resulting offsets per
cutting edge" can be defined per cutting edge but do not have to be. This means that
buffered memory can
be used economically. Only those cutting edges for which expliicit
data have been defined have a resulting offset data block.
Buffered memory is reserved. The memory requirement for a resulting offset doubles if
"setup offset active" has also been configured, see MD18112 $MN_MM_KIND_OF_SUMCORR.
See also:
MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA,
MD18110 $MN_MM_MAX_SUMCORR_PER_CUTTEDGE
18110 MM_MAX_SUMCORR_PER_CUTTEDGE N02, N09 S7
- Max. number of additive offsets per edge (SRAM) DWORD PowerOn
-
808d-me42 - 1 1 6 ReadOnly
808d-me62 - 1 1 6 ReadOnly
808d-te42 - 1 1 6 ReadOnly
808d-te62 - 1 1 6 ReadOnly
808d-mte40 - 1 1 6 7/2
808d-mte60 - 1 1 6 7/2
Description: Maximum number of resulting offsets per cutting edge.
If MD18108 $MN_MM_NUM_SUMCORR > 0 then:
The data is not memory defining, but is only used for monitoring.
If MD18108 $MN_MM_NUM_SUMCORR = -1 then:
The data is memory defining.
See also
MD18108 $MN_MM_NUM_SUMCORR,
MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA.
18112 MM_KIND_OF_SUMCORR N02, N09 W1
- Properties of resulting offsets in TO area (SRAM) DWORD PowerOn
-
808d-me42 - 0 0 0x1F ReadOnly
808d-me62 - 0 0 0x1F ReadOnly
808d-te42 - 0 0 0x1F ReadOnly
808d-te62 - 0 0 0x1F ReadOnly
808d-mte40 - 0 0 0x1F 7/2
808d-mte60 - 0 0 0x1F 7/2
Description: Properties of the resulting offsets in NCK.
Bit 0=0 "Resulting offsets fine" are backed up when the tool data are backed up.
Bit 0=1 "Resulting offsets fine" are backed up when the tool data are backed up.
Bit 1=0 Set-up offsets are backed up when the tool data are backed up.
Bit 1=1 Set-up offsets are not backed up when the tool data are backed up.
Bit 2=0 If work is done with the function tool management (TOOLMAN) and/or tool
monitoring (TMMO), existing "resulting offsets fine/setup offsets" are not affected
when the tool status is set to "active".
Bit 2 =1 Existing resulting offsets are set to zero when the tool status is set to
"active".
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 91
