Bit 3=0 If work is done with the function "TOOLMAN" +"adapter", the "resulting offsets
fine"/setup offsets are transformed.
Bit 3=1 No transformation of the "resulting offsets fine"/setup offsets
Bit 4=0 No set-up offset data blocks
Bit 4=1 Set-up offset data blocks are additionally created. Whereby the resulting
offset is composed of the sum of the set-up offset + "resulting offset fine"
Changing the status of bits 0, 1, 2, 3 does not change the memory structure.
Changing the status of bit 4 triggers restructuring of the buffered memory after the
next PowerOn.
See also
MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA
MD18108 $MN_MM_NUM_SUMCORR
MD18110 $MN_MM_MAX_SUMCORR_PER_CUTTEDGE
MD18080 $MN_MM_TOOL_MANAGEMENT_MASK,
MD20310 $MC_TOOL_MANAGEMENT_MASK,
MD18086 $MN_MM_NUM_MAGAZINE_LOCATION,
MD18104 $MN_MM_NUM_TOOL_ADAPTER
18114 MM_ENABLE_TOOL_ORIENT N02, N09 W1, F2
- Assign tool cutting edge orientation DWORD PowerOn
-
808d-me42 - 0 0 3 ReadOnly
808d-me62 - 0 0 3 ReadOnly
808d-te42 - 0 0 3 ReadOnly
808d-te62 - 0 0 3 ReadOnly
808d-mte40 - 0 0 3 7/2
808d-mte60 - 0 0 3 7/2
Description: The function allows an orientation deviating from the default value to be assigned to
each tool cutting edge.
Value = 0:
The tool orientation function is inactive.
Value = 1:
The system parameter $TC_DPV[n, m] is assigned to each tool cutting edge D=m of the
tool T=n, with the aid of which one of 6 possible tool orientations in positive or
negative coordinate direction can be defined.
Value = 2:
Not only the system parameter $TC_DPV[n, m] but also the additional three system
parameters
$TC_DPV3[n, m], $TC_DPV4[n, m] and $TC_DPV5[n, m] are assigned to each tool
cutting edge D=m of the tool T=n, with the aid of which any spatial tool orientation
can be defined
T, D are the NC addresses T and D with which the tool change or the tool selection and
the offset selection are programmed.
Value = 3:
Not only the system parameters $TC_DPV[n, m] and $TC_DPV3 - $TC_DPV5 but also the
additional three system parameters $TC_DPVN3[n, m], $TC_DPVN4[n, m] and $TC_DPVN5[n,
m] are assigned to each tool cutting edge D=m of the tool T=n, with the aid of which
a vector (normal vector) can be defined that is preferably perpendicular to the tool
orientation.
The normal vector may be modified so that it lies in the plane formed by
the orientation and the programmed normal vector but perpendicular to the orientation
The orientation and the possibly modified normal vector together define a complete
orientation coordinate system. The machine data affects the requirement for battery-
backed memory.
Machine data
3.2 General machine data
Parameter Manual
92 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
