18118 MM_NUM_GUD_MODULES N02 S7
- Number of GUD files in active file system (SRAM) DWORD PowerOn
-
808d-me42 - 1 1 1 0/0
808d-me62 - 1 1 1 0/0
808d-te42 - 1 1 1 0/0
808d-te62 - 1 1 1 0/0
808d-mte40 - 7 1 9 7/2
808d-mte60 - 7 1 9 7/2
Description: A GUD block corresponds to a file in which user-defined data can be stored. 9 GUD
blocks are available of which 3 are already assigned to specific users/applications.
UGUD_DEF_USER (block for user)
SGUD_DEF_USER (block for SIEMENS)
MGUD_DEF_USER (block for machine manufacturer)
Special cases:
The number of GUD modules is determined by the GUD module with the highest number
entered.
Example:
If the following GUD modules are defined,
UGUD
MGUD
GUD5
GUD8
then the machine data must be set to a value of 8, signifying a memory requirement of
8 x 120 bytes = 960 bytes.
It is therefore advisable to selected the "lowest" possible GUD module. If GUD modules
UGUD
and MGUD
have not been assigned elsewhere, then they may be used for this purpose.
Related to:
MD18150 $MN_MM_GUD_VALUES_MEM
(Memory space for user variables)
18120 MM_NUM_GUD_NAMES_NCK N02 S7
- Number of global user variable names (SRAM) DWORD PowerOn
-
808d-me42 - 60 60 32000 0/0
808d-me62 - 60 60 32000 0/0
808d-te42 - 60 60 32000 0/0
808d-te62 - 60 60 32000 0/0
808d-mte40 - 60 60 32000 7/2
808d-mte60 - 60 60 32000 7/2
Description: Defines the number of user variables for NCK global user data (GUD). Approximately 80
bytes of memory
per variable are reserved in the SRAM for the names of the variables.
The additional memory required for the value of the variable depends on the data type
of the variable. The number of available NCK global user data is exhausted on reaching
the limit value set in MD18120 $MN_MM_NUM_GUD_NAMES_NCK or MD18150
$MN_MM_GUD_VALUES_MEM (memory space for user variables).
Buffered user memory is used.
Special cases:
The battery-backed data are lost if this machine data is altered.
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 93
