FRAME up to 1KB depending on control model
The total memory required by a channel or axis-specific global user variable is the
memory requirement of
the variables multiplied by the number of channels or axes. The
number of global user variables available is given when the limit defined in MD18120
$MN_MM_NUM_GUD_NAMES_NCK, MD18130 $MN_MM_NUM_GUD_NAMES_CHAN, MD18140
$MN_MM_NUM_GUD_NAMES_AXIS or MD18150 $MN_MM_GUD_VALUES_MEM is reached.
Buffered user memory is used.
Special cases:
The buffered data are lost if this machine data is altered!
Related to:
MD18118 $MN_MM_NUM_GUD_MODULES
(Number of GUD blocks)
MD18120 $MN_MM_NUM_GUD_NAMES_NCK
(Number of global user variables)
MD18130 $MN_MM_NUM_GUD_NAMES_CHAN
(Number of channel-specific user variables)
18170 MM_NUM_MAX_FUNC_NAMES N02 V2, A2
- Number of miscellaneous functions (cycles, DRAM) DWORD PowerOn
-
808d-me42 - 100 0 32000 0/0
808d-me62 - 100 0 32000 0/0
808d-te42 - 100 0 32000 0/0
808d-te62 - 100 0 32000 0/0
808d-mte40 - 100 0 32000 7/2
808d-mte60 - 100 0 32000 7/2
Description: The data limits the maximum number of special functions over and above the predefined
functions (such as sine, cosine, etc.) which can be used in
● cycle programs
● compile cycle software.
The function names are entered in the global NCK dictionary and must not conflict with
the names that already exist.
The SIEMENS cycle package contains special functions that are taken into account by
the default setting of the MD.
The data are stored in unbuffered memory. Approximately 150 bytes are required for
each special function for management purposes.
Related to:
MD18180 $MN_MM_NUM_MAX_FUNC_PARAM
(Number. of additional parameters)
18180 MM_NUM_MAX_FUNC_PARAM N02 V2
- Number of additional parameters for cycles according to MD 18170 DWORD PowerOn
-
808d-me42 - 1000 0 32000 0/0
808d-me62 - 1000 0 32000 0/0
808d-te42 - 1000 0 32000 0/0
808d-te62 - 1000 0 32000 0/0
808d-mte40 - 1000 0 32000 7/2
808d-mte60 - 1000 0 32000 7/2
Description: Defines the maximum number of parameters required for the special functions in
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 95
