● cycle programs
● compile cycle software.
50 parameters are required for the special functions of the SIEMENS cycle package,
software version 1.
The data are stored in unbuffered memory. 72 bytes of memory are reserved for each
parameter.
Related to:
MD18170 $MN_MM_NUM_MAX_FUNC_NAMES
(Number of special functions)
18190 MM_NUM_PROTECT_AREA_NCK N12, N02, N06,
N09
A3
- Number of control-specific protection areas (SRAM) DWORD PowerOn
-
808d-me42 - 10 0 10 1/1
808d-me62 - 10 0 10 1/1
808d-te42 - 10 0 10 1/1
808d-te62 - 10 0 10 1/1
808d-mte40 - 0 0 10 1/1
808d-mte60 - 0 0 10 1/1
Description: This machine data defines how many control-specific protection areas have been created.
Related to:
MD28200 $MC_MM_NUM_PROTECT_AREA_CHAN (number of channel-specific protection areas)
MD28210 $MC_MM_NUM_PROTECT_AREA_ACTIVE (number of simultaneously active protection
areas)
References:
/FB/, A3, "Axis Monitoring, Protection Areas"
18204 MM_NUM_CCS_TDA_PARAM N02, N09 FBWsl
- Number of Siemens OEM tool data (SRAM) DWORD PowerOn
-
808d-me42 - 0 0 10 2/2
808d-me62 - 0 0 10 2/2
808d-te42 - 0 0 10 2/2
808d-te62 - 0 0 10 2/2
808d-mte40 - 0 0 10 0/0
808d-mte60 - 0 0 10 0/0
Description: Only when MD18080 $MN_MM_TOOL_MANAGEMENT_MASK, bit 2=1 ('H4'), is set:
User or OEM data of the tools.
Number of Siemens OEM TDA (=tool-specific) data (standard format Int).
See also: MD18094 $MN_MM_NUM_CC_TDA_PARAM, MD18082 $MN_MM_NUM_TOOL
Buffered user memory is used
18206 MM_NUM_CCS_TOA_PARAM N02, N09 FBWsl
- No. of Siemens OEM data per cutting edge (SRAM) DWORD PowerOn
-
808d-me42 - 0 0 10 2/2
808d-me62 - 0 0 10 2/2
808d-te42 - 0 0 10 2/2
Machine data
3.2 General machine data
Parameter Manual
96 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
