808d-te62 - 0 0 10 2/2
808d-mte40 - 0 0 10 0/0
808d-mte60 - 0 0 10 0/0
Description: Only when MD18080 $MN_MM_TOOL_MANAGEMENT_MASK, bit 2=1 ('H4'), is set:
User or OEM data of the tools.
Number of Siemens OEM TOA data (standard format IN_Real).
See also: MD18096 $MN_MM_NUM_CC_TOA_PARAM, MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA
Buffered user memory is used
18207 MM_TYPE_CCS_TOA_PARAM N02, N09 FBWsl
- Type of Siemens OEM data per cutting edge (SRAM) DWORD PowerOn
-
808d-me42 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2
808d-me62 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2
808d-te42 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2
808d-te62 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 2/2
808d-mte40 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 0/0
808d-mte60 10 4, 4, 4, 4, 4, 4, 4, 4... 1 6 0/0
Description: Only when MD18080 $MN_MM_TOOL_MANAGEMENT_MASK, bit 2=1 ('H4'), is set:
User or OEM data in the tool management.
Type of cutting-edge-specific Siemens user data configured by MD18206
$MN_MM_NUM_CCS_TOA_PARAM.
Each parameter can be assigned its own type. The permissible types are
Type Value of the machine data
(See types of the NC language)
----------------------------------------------------------------
BOOL 1
CHAR 2
INT 3
REAL 4
● (STRING is explicitly impossible here; value 5 is treated like value 2)
AXIS 6
FRAME not defined
See also: MD18206 $MN_MM_NUM_CCS_TOA_PARAM, MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA
Buffered user memory is used. A change in value leads to reconfiguration of the
buffered memory.
18208 MM_NUM_CCS_MON_PARAM N02, N09 FBWsl
- No. of Siemens OEM monitor data (SRAM) DWORD PowerOn
-
808d-me42 - 0 0 10 2/2
808d-me62 - 0 0 10 2/2
808d-te42 - 0 0 10 2/2
808d-te62 - 0 0 10 2/2
808d-mte40 - 0 0 10 0/0
808d-mte60 - 0 0 10 0/0
Description: Only when MD18080 $MN_MM_TOOL_MANAGEMENT_MASK, bit 0 = 1 or bit 1 = 1 and bit 2=1
('H4'), is set:
User or OEM data in the tool management.
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 97
