Number of Siemens OEM monitoring data; standard format IN_Int).
See also: MD18098 $MN_MM_NUM_CC_MON_PARAM, MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA
Buffered user memory is used
18230 MM_USER_MEM_BUFFERED N02 S7
- Buffered user memory DWORD PowerOn
NDLD
808d-me42 - - 0 7168 0/0
808d-me62 - - 0 7168 0/0
808d-te42 - - 0 7168 0/0
808d-te62 - - 0 7168 0/0
808d-mte40 - - 0 7168 ReadOnly
808d-mte60 - - 0 7168 ReadOnly
Description: Nonvolatile user memory (in kB).
Various types of user data are stored in this memory area.
For example:
● NC part programs
● R variables
● Global user data (GUD)
● Definitions of the protection zones
● Correction tables EEC, CEC, QEC
● Tool / magazine data
...
This data is retained after control power-off.
(Provided the data backup (battery,...) is in good working order, i.e. the Init switch
is correctly set on the control).
This means that they are available unchanged after restart.
Each additional active channel occupies some nonvolatile memory. With channel
activation, the value of the MD is automatically increased accordingly; the value of
MD18060 $MN_INFO_FREE_MEM_STATIC is retained if possible.
To enlarge this user memory further, MD19250 $ON_USER_MEM_BUFFERED must be increased.
The available values depend on the hardware and software configurations.
Information alarms 6030, 6035 can indicate that the desired total memory may not be
available
on the
model or on the hardware. See also MD11415 $MN_SUPPRESS_ALARM_MASK_2,
bit 22
See also the meaning of MD18060 $MN_INFO_FREE_MEM_STATIC
18321 MM_NUM_SYSTEM_FILES_IN_FS N02 -
- Number of system files DWORD PowerOn
-
808d-me42 2 300, 0 300, 0 1000, 1000 0/0
808d-me62 2 300, 0 300, 0 1000, 1000 0/0
808d-te42 2 300, 0 300, 0 1000, 1000 0/0
808d-te62 2 300, 0 300, 0 1000, 1000 0/0
808d-mte40 2 500, 0 500, 0 1000, 1000 1/1
808d-mte60 2 500, 0 500, 0 1000, 1000 1/1
Description: Index 0: Number of temporary system files in the passive file system (see also MD18355
$MN_MM_T_FILE_MEM_SIZE);
e.g.: system traces
Machine data
3.2 General machine data
Parameter Manual
98 Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1
