Index 1: Number of temporary Siemens cycles in the passive file system (see also
MD18354 $MN_MM_S_FILE_MEM_SIZE):
The data can be written, but will be overwritten during the runup by the value
requested by the Siemens cycles.
18342 MM_CEC_MAX_POINTS N01, N02 K3
- Max. number of interpolation points on sag compensation (SRAM) DWORD PowerOn
-
808d-me42 6 128, 128, 128, 128,
128, 128, 0, 0
0 128 ReadOnly
808d-me62 8 128, 128, 128, 128,
128, 128, 128, 128
0 128 ReadOnly
808d-te42 6 128, 128, 128, 128,
128, 128, 0, 0
0 128 ReadOnly
808d-te62 8 128, 128, 128, 128,
128, 128, 128, 128
0 128 ReadOnly
808d-mte40 6 128, 128, 128, 128,
128, 128, 0, 0
0 128 7/2
808d-mte60 8 128, 128, 128, 128,
128, 128, 128, 128
0 128 7/2
Description: The MD defines the memory space available for the compensation tables.
When MD18342 $MN_MM_CEC_MAX_POINTS = 0, no memory is set up for the table. The sag
compensation function cannot then be used.
Caution!
If MD18342 $MN_MM_CEC_MAX_POINTS[t] is changed, when the system is powered up, the
buffered NC user memory is automatically reset. This deletes all user data in the
buffered user memory (e.g. drive and HMI machine data, tool offsets, part programs
etc.).
Related to:
SD41300 $SN_CEC_TABLE_ENABLE[t]
Evaluation of the sag compensation table (t) enabled.
References:
/FB/, S7, "Memory Configuration"
18352 MM_U_FILE_MEM_SIZE EXP, N02 S7
- End user memory for part programs/cycles/files DWORD PowerOn
-
808d-me42 3 1280, 0, 0 0 1280 0/0
808d-me62 3 1280, 0, 0 0 1280 0/0
808d-te42 3 1280, 0, 0 0 1280 0/0
808d-te62 3 1280, 0, 0 0 1280 0/0
808d-mte40 3 1280, 0, 0 0 1280 2/2
808d-mte60 3 1280, 0, 0 0 1280 2/2
Description: The machine data is not available or not defined for PowerLine control models.
End user memory for files in the passive file system ( in kbyte ).
There are various types of user data in this memory area.
E.g.: NC part programs, cycle programs of the end user, diagnostic files, ....
The settable values depend on the hardware and software configurations.
The settable size of the part program memory is, apart from the upper limit value,
determined by the MD18230 $MN_MM_USER_MEM_BUFFERED and can also
be determined by a software option.
Machine data
3.2 General machine data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 99
