Explanation of machine data and setting data
1.1 Data in the list
Parameter Manual
10
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Cross reference
For a detailed description of the appropriate data, refer to the description of functions or
manual/guide specified.
Attributes
The "Attributes" field contains additional attributes of the data:
Unit/unit system
Depending on MD10240 SCALING_SYSTEM_IS_METRIC, the physical units of the machine
data (MD) differ as follows:
If there are machine data with no physical unit assigned, a hyphen ("-
") can be found in the
relevant field.
Dimension
The "Dimension" field contains the number of elements of a data field.
Attribute Meaning
NBUP No Back UP: The data is not backed up as part of the data backup.
ODLD Only DownLoaD: The data can only be written to via an INI file, archive, or from the part
program.
NDLD No DownLoaD: The data can only be written to via the HMI user interface.
SFCO SaFety COnfiguration: Component of the "Safety Integrated" function
SCAL SCaling ALarm: Scaling data; when changed, alarm 4070 is displayed
LINK LINK description: The data describes a link cluster, component of the "NCU Link" function
CTEQ ConTainer EQual: The data must be the same for all axes in an axis container, component
of the "Axis container" function
CTDE ConTainer DEscription: The data describes an axis container, component of the "Axis
container" function
MD10240 = 1 MD10240 = 0
mm inch
mm/min inch/min
m/s
2
inch/s
2
m/s
3
inch/s
3
mm/rev. inch/rev.
Note
The default setting for MD10240 SCALING_SYSTEM_IS_MERIC is "1".
