Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
109
Machine data
2.3 Channel-specific machine data
$MC_GCODE_RESET_VALUES
Bit 5 = 0:
The current setting for G code "settable work offset" is retained.
Bit 5 = 1:
Initial setting for G code "settable work offset" according to MD20150
$MC_GCODE_RESET_VALUES
Bit 6 = 0:
The current setting for active tool length offset is retained.
If tool or magazine management is active, the tool currently on the active
toolholder (spindle) is always selected.
If the tool that is currently on the spindle is disabled, it is automatically
replaced by a suitable spare tool.
If such a spare tool does not exist, an alarm is output.
Bit 6 = 1:
Initial setting for active tool length offset according to MD20120
$MC_TOOL_RESET_VALUE, MD20130 $MC_CUTTING_EDGE_RESET_VALUE, MD20123
$MC_USEKT_RESET_VALUE, and MD20132 $MC_SUMCORR_RESET_VALUE.
If MD22550 $MC_TOOL_CHANGE_MODE == 1, the tool selected via MD20121
$MC_TOOL_PRESEL_RESET_VALUE is preselected in addition.
If tool or magazine management is active, MD20120 $MC_TOOL_RESET_NAME is used
instead of MD20122 $MC_TOOL_RESET_VALUE.
Bit 7 = 0:
The current setting for active transformation is retained.
Bit 7 = 1:
Initial setting for active transformation after reset/end-of-part-program
according to MD20140 $MC_TRAFO_RESET_VALUE
Bit 8 = 0:
Coupled-motion axis groupings remain active.
Bit 8 = 1:
Coupled-motion axis groupings are ungrouped.
Bit 9 = 0:
Tangential correction remains active.
Bit 9 = 1:
Tangential correction is switched off.
Bit 10 = 0:
Non-configured synchronous spindle coupling remains active.
Bit 10 = 1:
Non-configured synchronous spindle coupling is switched off.
Bit 11 : Reserved (revolutional feedrate)
Bit 12 = 0:
A changed geometry axis assignment remains active when the part program
starts up.
Bit 12 = 1:
If machine data MD20118 $MC_GEOAX_CHANGE_RESET is set, a changed geometry
axis assignment is deleted when the part program starts up.
Bit 13 = 0:
Master value couplings remain active.
Bit 13 = 1:
Master value couplings are canceled.
Bit 14 : Reserved (basic frame)
