Machine data
2.3 Channel-specific machine data
Description: Definition of the preselected tool in MD20310 $MC_TOOL_MANAGEMENT_MASK=1.
A tool is selected after runup, or on reset or part program end as a function
of MD20110 $MC_RESET_MODE_MASK, and on part program start as a function of
MD20112 $MC_START_MODE_MASK.
This MD is valid only without tool management.
Related to:
MD20110 $MC_RESET_MODE_MASK
MD20112 $MC_START_MODE_MASK
Description: Definition of the cutting edge for which tool length compensation is selected
during runup or on reset or part program end as a function of MD20110
$MC_RESET_MODE_MASK, and as a function of MD20112 $MC_START_MODE_MASK on part
program start.
With active tool management and with bit 0 and bit 6 set in MD20110
$MC_RESET_MODE_MASK at selection, the last offset of the tool active at power
OFF - as a rule the tool on the spindle - is effective after runup.
Related to:
MD20110 $MC_RESET_MODE_MASK
MD20112 $MC_START_MODE_MASK
20121 TOOL_PRESEL_RESET_VALUE C03 K1,W1
- Preselected tool on RESET DWORD Reset
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1
20130 CUTTING_EDGE_RESET_VALUE C03 -
- Tool edge with length compens. during runup (reset/end of pp) DWORD Reset
-
- - 1, 1, 1, 1, 1, 1, 1, 1... 0 32000 1/1
