Machine data
2.3 Channel-specific machine data
Parameter Manual
112 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
In spite of the set read-in disable, an assigned user ASUB is completely exe-
cuted for the interrupt channel with the set bit.
Bit 0 is assigned to interrupt channel 1.
Bit 1 is assigned to interrupt channel 2, etc.
Related to:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
Description: In spite of the set single-block processing mode, an assigned user ASUB is
completely executed for the relevant channel with the set bit.
Bit 0 is assigned to interrupt channel 1.
Bit 1 is assigned to interrupt channel 2, etc.
The MD is only active with single block type 1.
Related to:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20116 $MC_IGNORE_INHIBIT_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
Description: Definition of the tool for which tool length compensation is selected during
runup or on reset or part program end as a function of MD20110
$MC_RESET_MODE_MASK, and on part program start as a function of MD20112
$MC_START_MODE_MASK
Related to:
MD20110 $MC_RESET_MODE_MASK
MD20112 $MC_START_MODE_MASK
20116 IGNORE_INHIBIT_ASUP C01 K1,Z1
- Execute interrupt program despite read-in disable DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 - 2/2
20117 IGNORE_SINGLEBLOCK_ASUP C01 K1,Z1
- Execute interrupt program completely despite single block DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 - 2/2
20120 TOOL_RESET_VALUE C03 K1,W1
- Tool with length compens. during runup (reset/part program
end).
DWORD Reset
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1
