Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
111
Machine data
2.3 Channel-specific machine data
Description: After program interruption in MDI mode (e.g. in order to carry out a measure-
ment on the workpiece and to correct the tool wear values or after tool
breakage) the tool can be manually withdrawn from the contour by changing
into JOG mode.
In this case, the control stores the coordinates of the position of the
interruption and indicates the path differences traversed by the axes in JOG
mode as "Repos offset". When MDI mode is selected again, the axis is reposi-
tioned on the contour. This response can be canceled by means of this machine
data.
Bit 0 (LSB)= 0:
When MDI (JOG, JOGREF, JOGREPOS, MDIREF and MDIREPOS) are deselected in
stopped status, the system ASUB Repos is selected.
Bit 0 (LSB) = 1:
When MDI (JOG, JOGREF, JOGREPOS, MDIREF and MDIREPOS) are deselected in
stopped status, the system ASUB Repos is not selected.
Bit 1 (LSB) = 0:
If the NCK stops at a part program block in the program execution in which
repositioning is not possible, alarm 16916 is generated if an attempt is made
to switch to manual mode.
Bit 1 (LSB) = 1:
If the NCK stops at a part program block in the program execution in which
repositioning is not possible, no alarm is generated if an attempt is made to
switch to manual mode.
Description: Despite non-referenced axes, an assigned user ASUB is processed for the
interrupt whose bit is set.
Bit 0 is assigned to interrupt 1.
Bit 1 is assigned to interrupt channel 2, etc.
Corresponds to:
MD11602 $MN_ASUP_START_MASK
MD20116 $MC_IGNORE_INHIBIT_ASUP
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
The machine data MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK and MD20115
$MC_IGNORE_REFP_LOCK_ASUP replace bit 1 from MD11602 $MN_ASUP_START_MASK.
If MD20700 $MC_REFP_NC_START_LOCK is equal to 0, the setting in MD20105
$MC_PROG_EVENT_IGN_REFP_LOCK will be ignored.
20114 MODESWITCH_MASK C03 K1
- Interruption MDI by mode change DWORD Reset
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0xFFFF 1/1
20115 IGNORE_REFP_LOCK_ASUP C01 K1,Z1
- Process interrupt program despite non-referenced axes DWORD NEW CONF
-
- - 0x200, 0x200, 0x200,
0x200, 0x200,
0x200...
0 - 2/2
