Machine data
2.3 Channel-specific machine data
Parameter Manual
120
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
If the ASUB is started, OPI variables
progStatus and chanStatus do not change, i.e. the HMI does not see this nor-
mally short program execution.
Bit 0 is assigned to interrupt channel 1.
Bit 1 is assigned to interrupt channel 2, etc.
Korrespondiert mit:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20116 $MC_IGNORE_INHIBIT_ASUP
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
MD20194 $MC_IGNORE_NONCSTART_ASUP
Description: Event-driven program calls (Prog-Events) can be set regarding their response
on the OPI.
The progStatus and chanStatus variables remain unaffected despite Prog-Event
processing being active and retain the old value. This provides a means of
concealing Prog-Event processing from the HMI.
Bit 0 = 1 :
Reserved bit, ineffective
Bit 1 = 1 :
Prog-Event after end-of-part-program does not change progStatus and chanSta-
tus
Bit 2 = 1 :
Prog-Event after OP reset does not change progStatus and chanStatus
Bit 3 = 1 :
Prog-Event after ramp-up does not change progStatus and chanStatus
Bit 4 = 1 :
Reserved
Bit 5 = 1 :
Safety-Prog-Event during ramp-up does not change progStatus and chanStatus
Corresponds to:
MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK
MD20106 $MC_PROG_EVENT_IGN_SINGLEBLOCK
MD20107 $MC_PROG_EVENT_IGN_INHIBIT
MD20108 $MC_PROG_EVENT_MASK
MD20193 $MC_PROG_EVENT_IGN_STOP
20191 IGN_PROG_STATE_ASUP EXP K1
- Do not display interrupt program execution on OPI DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 - 2/2
20192 PROG_EVENT_IGN_PROG_STATE EXP -
- Do not display the Prog-Event on OPI DWORD NEW CONF
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x3F 2/2
