Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
121
Machine data
2.3 Channel-specific machine data
Description: Event-controlled program calls (Prog-Events) can be influenced with regard to
their behavior after pressing of the stop key.
The Stop, StopAll and StopAtEnd key of the PLC is ignored, if required.
Bit 0 = 1 :
Prog-Event after part program start delays the stop until the part program
starts, i.e. the stop only becomes active in the part program, not before its
start. If the part program starts with a traversing block, it is possible
that it starts briefly, i.e. a short motion occurs, although Stop has already
been pressed in the Start-Prog-Event.
Bit 1 = 1 :
Prog-Event after part program end ignores the stop
Bit 2 = 1 :
Prog-Event after operator panel reset ignores the stop
Bit 3 = 1 :
Prog-Event after power up ignores the stop
Corresponds to:
MD20105 $MC_PROG_EVENT_IGN_REFP_LOCK
MD20106 $MC_PROG_EVENT_IGN_SINGLEBLOCK
MD20107 $MC_PROG_EVENT_IGN_INHIBIT
MD20108 $MC_PROG_EVENT_MASK
MD20192 $MC_PROG_EVENT_IGN_PROG_STATE
Description: If a user alarm is present from the number range 65500-65999, an ASUB start
from reset is permitted in spite of the response "Interlock NC-START", which
has these alarms. An ASUB start from an active or stopped state is not influ-
enced by this.
Bit 0 is assigned to interrupt 1.
Bit 1 is assigned to 2, etc.
Corresponds with:
MD11602 $MN_ASUP_START_MASK
MD20115 $MC_IGNORE_REFP_LOCK_ASUP
MD20116 $MC_IGNORE_INHIBIT_ASUP
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
MD20191 $MC_IGN_PROG_STATE_ASUP
20193 PROG_EVENT_IGN_STOP EXP -
- Prog-Events ignore the stop key DWORD NEW CONF
-
- - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0xF 2/2
20194 IGNORE_NONCSTART_ASUP EXP K1
- Permit ASUB in spite of "Interlock NC-START" if user alarms
present.
DWORD NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... - - 2/2
